| Hybrid ball bearing (pcs) | 4 |
| Lifetime lubricated | maintenance free |
| Motor technology |
3-phase asynchronous drive (no brushes or sensors) |
| Frequency | 1000 Hz |
| Motor poles (pairs) | 1 |
| Rated Rotation Speed | 60,000 rpm |
| Rated Power (Pmax/5s) | 3.2 kW |
| Rated Power (S6-60%) | 2.1 kW |
| Rated Power (S1-100%) | 1.8 kW |
| Voltage (Pmax/5s) | 185 V |
| Voltage (S6-60%) | 188 V |
| Voltage (S1-100%) | 188 V |
| Current (Pmax/5s) | 16 A |
| Current (S6-60%) | 10.5 A |
| Current (S1-100%) | 9.1 A |
| Speed Sensor |
Differential magneto resistor (TTL) Number of signals = 6 |
| Motor protection | PTC 130°C |
| Housing | Stainless steel |
| Housing diameter | 61,9 mm |
| Cooling | Liquid cooled |
| Sealing Air | yes |
| Protection category | IP54 |
| Taper Cleaning | yes |
| Tool Change | Pneumatic taper change |
| Tool Holder | WK 16 |
| Clamping status monitoring | inductive |
| Collet type |
ER 11 / D 8 Optional accessories |
| Clamping range | 8 mm ( 5/16" ) |
| Direction of motion | Clockwise and anticlockwise |
| Coupler plug |
Y-TEC 9-pin(motor phases) 12-pin(sensors) |
| Weight | 6.6 kg |
| Concentricity | <1 µ |
| Axial run-out | <1 µ |
