| Hybrid ball bearing (pcs) | 2 |
| Lifetime lubricated | maintenance free |
| Motor technology |
3-phase asynchronous drive (no brushes or sensors) |
| Frequency | 833 Hz |
| Motor poles (pairs) | 1 |
| Rated Rotation Speed | 50,000 rpm |
| Rated Power (Pmax/5s) | 3.2 kW |
| Rated Power (S6-60%) | 2.5 kW |
| Rated Power (S1-100%) | 2.3 kW |
| Voltage (Pmax/5s) | 167 V |
| Voltage (S6-60%) | 167 V |
| Voltage (S1-100%) | 167 V |
| Current (Pmax/5s) | 15.9 A |
| Current (S6-60%) | 12.9 A |
| Current (S1-100%) | 12 A |
| Speed Sensor |
Differential magneto resistor (TTL) Number of signals = 6 |
| Housing | Stainless steel |
| Housing diameter | 80 mm |
| Cooling | Liquid cooled |
| Ambient temperature | + 10°C … + 45°C |
| Sealing Air | yes |
| Protection category | IP54 |
| Taper Cleaning | yes |
| Tool Change | Pneumatic taper change |
| Tool Holder | WK 19 |
| Collet type |
D8 Optionales Zubehör |
| Clamping range | 8 mm ( 5/16" ) |
| Direction of motion | Clockwise |
| Coupler plug | 8-pin (SpeedTEC) |
| Weight | 5.3 kg |
| Concentricity | <1 µ |
| Axial run-out | <1 µ |
